Model No：KFL7530
Measure：75*75*30 mm
Feature：
．Housing: enviromental protection and fireproof PBT（UL94V-0）.
．Impeller: enviromental protection and fireproof PBT（UL94V-0）.
．Enameled copper wire: BA class insulation,withstand high temperature 155℃.
．Bearing: high-precision,long-life and low noise ball bearing.
．Motor: Impedance protection.
Operating temperature：
ball bearing:-30℃ to + 75℃ 30%-85% RH
sleeve bearing:-10℃ to + 70℃ 30%-85% RH
Specifications :
Model No. | Voltage | Operating Voltage | Current | Power | Speed | Speed | Static Pressure | Noise | ||
V | V | A | W | RPM | M³/Min | CFM | mmH2O | inH2O | dB-A | |
KFL753012L | 12 | 6.0~13.5 | 0.12 | 1.44 | 2000 | 0.18 | 6.31 | 5.04 | 0.20 | 32 |
KFL753024L | 24 | 18~26.5 | 0.08 | 1.92 | ||||||
KFL753012M | 12 | 6.0~13.5 | 0.23 | 2.76 | 2500 | 0.24 | 8.34 | 6.40 | 0.26 | 38 |
KFL753024M | 24 | 18~26.5 | 0.11 | 2.64 | ||||||
KFL753012H | 12 | 6.0~13.5 | 0.22 | 2.64 | 3000 | 0.29 | 10.35 | 8.96 | 0.38 | 42 |
KFL753024H | 24 | 18~26.5 | 0.14 | 3.36 | ||||||
KFL753048H | 48 | 36~54 | 0.07 | 3.36 | ||||||
KFL753012H-HH | 12 | 6.0~13.5 | 0.35 | 4.20 | 3400 | 0.31 | 10.98 | 12.53 | 0.50 | 44 |
KFL753024H-HH | 24 | 18~26.5 | 0.20 | 4.80 | ||||||
KFL753048H-HH | 48 | 36~54 | 0.09 | 4.32 | ||||||
KFL753024H-VH | 24 | 18~26.5 | 0.30 | 7.20 | 3700 | 0.36 | 12.66 | 16.28 | 0.64 | 46 |
KFL753048H-VH | 48 | 36~54 | 0.11 | 5.28 | ||||||
 |  |
